1. Introduction to the Pentair VT 5600SXT Water Softener
The Pentair VT 5600SXT is one of the most popular digital metered water softener control valves used in residential settings. Known for its reliability, customizable features, and user-friendly LCD interface, this Fleck-based model is designed to monitor water usage and regenerate only when necessary—saving salt, water, and energy.
Programming the unit properly ensures optimal performance and extended system life. Whether you’re installing the system for the first time or reconfiguring it after a power outage or service call, understanding how to program the Pentair VT 5600SXT is essential.
This guide walks you through the core programming functions, from setting time and hardness levels to advanced regeneration cycles and troubleshooting.
2. Initial Setup: Before You Begin Programming
Tools and Information You’ll Need
Before jumping into the programming menu, it’s important to gather some basic information:
Water hardness level (in grains per gallon or ppm)
Household size and average water usage
System capacity (e.g., 32,000 or 48,000 grains)
Optional: iron content in water (if any)
You’ll also need:
A small screwdriver (for valve cover removal, if needed)
A user manual (available online or from Pentair/Fleck)
Accessing the Programming Mode
To begin programming:
Press and hold the “Up” and “Down” arrow buttons simultaneously for 5 seconds.
The display will enter the Master Programming Mode (MP mode).
Use the “Set/Change” button to toggle between settings, and the arrow keys to adjust values.
Note: If the screen is locked or unresponsive, check for power issues or try holding all three buttons (up, down, set) to reset.
Safety and Electrical Considerations
Ensure the softener is connected to a surge-protected power source, and keep the area dry. The control head runs on low voltage (12V), but water and electricity still require care. Never disassemble the unit while plugged in unless instructed.
3. Key Programming Parameters and What They Mean
Setting the Current Time of Day
From the home screen:
Press “Set/Change” once.
The hour digit will blink; use arrows to set the correct time (24-hour or 12-hour format).
Press “Set/Change” again to adjust minutes.
Once set, press and hold “Set/Change” for 3 seconds to save and exit.
This ensures regeneration cycles happen at the correct time (typically 2 a.m. by default).
Setting Water Hardness Level
In Master Programming Mode:
Locate the setting labeled “HARD” or “Hardness”.
Use arrow keys to input your water hardness level (in grains per gallon).
If you have iron in the water, add 5 grains for each 1 ppm of iron to your hardness total.
This setting tells the system how many gallons to process before regenerating, based on your household’s needs.
Capacity and Reserve Settings
Depending on the size of your unit (e.g., 32k, 48k):
Enter the system capacity (e.g., 32 for 32,000 grains).
Set the reserve capacity as either a fixed number or percentage.
Fixed Reserve: gallons
Variable Reserve: % of capacity
A reserve ensures you don’t run out of soft water before the next regeneration. Variable reserve is more efficient and is the default on newer systems.
4. Advanced Programming and Regeneration Settings
Setting Regeneration Mode
There are several regeneration types:
Meter Delayed (Md): Regenerates when capacity is met, but delays until the set time.
Meter Immediate (MI): Regenerates as soon as capacity is met.
Time Clock Delayed (Td): Regenerates at a fixed interval (e.g., every 3 days).
Time Clock Immediate (TI): Rarely used; regenerates as soon as the timer hits.
For most homes, Meter Delayed (Md) is ideal for saving salt and water.
Adjusting Cycle Times
The 5600SXT allows you to customize cycle lengths:
Backwash (BW): Usually 10–12 minutes
Brine Draw (BD): 60–90 minutes
Rapid Rinse (RR): 5–10 minutes
Refill (RF): 5–7 minutes depending on tank size
Shortening cycles saves time, but must be done carefully to ensure resin is cleaned and tank is refilled adequately.
Salt and Brine Settings
The brine refill time controls how much salt water is drawn into the resin tank. The default refill rate is 0.5 gallons per minute. Multiply the refill time by 0.5 to estimate gallons.
Example:
Refill time = 6 minutes → 3 gallons
This amount of brine draws ~9 lbs of salt (3 lbs per gallon, depending on system design)
Adjust this if your water usage increases or you see signs of under-softening.
5. Troubleshooting and Best Practices
If your Pentair VT 5600SXT system is not softening properly or regenerating at odd times, the issue is often programming-related.
Common problems include:
Incorrect hardness settings
System not set to “Meter Delayed”
Reserve capacity too low
Brine line clogs or empty salt tank
Best practices:
Check salt levels weekly
Clean the injector screen every 6–12 months
Power cycle the unit after major setting changes
Recalibrate settings after any plumbing or household occupancy changes
Keep a log of all settings and changes. If you lose power for an extended time, only the clock resets; programming remains stored in memory.
Final Thoughts
Programming the Pentair VT 5600SXT water softener may seem technical at first, but once you understand the purpose of each setting, the process becomes simple and intuitive. Accurate programming leads to consistent water quality, reduced maintenance, and long-term system reliability.
Whether you’re a new homeowner setting up your first system or a technician fine-tuning an install, this guide ensures your water softener is working exactly as it should — intelligently, efficiently, and automatically.
